Exploded View iMac Retina 4K 21.5-inch 2019

iMac Retina 4K 21.5-inch 2019 - Exploded View



LCD Display Panel Assembly 4k Retina w/ Glass
661-07322

LCD Display Panel Assembly 4k Retina w/ Glass 661-07322 for iMac Retina 4K 21.5-inch 2019
Display / LVDS / eDP Cable 4k Retina
923-01669

Display / LVDS / eDP Cable 4k Retina 923-01669 for iMac Retina 4K 21.5-inch 2019
Camera / iSight Cable
923-01622

Camera / iSight Cable 923-01622 for iMac Retina 4K 21.5-inch 2019
CPU Cooling Fan
923-00563

CPU Cooling Fan 923-00563 for iMac Retina 4K 21.5-inch 2019
Hard Drive / Solid State SATA
661-01029, 661-10239, 661-10240, 661-10241, 661-6041, 661-6042, 661-6044, 661-6591, 661-7024

Hard Drive / Solid State SATA 661-01029, 661-10239, 661-10240, 661-10241, 661-6041, 661-6042, 661-6044, 661-6591, 661-7024 for iMac Retina 4K 21.5-inch 2019
Chin Strap
923-01678

Chin Strap 923-01678 for iMac Retina 4K 21.5-inch 2019
Power Supply Unit (PSU) 185W
661-7111

Power Supply Unit (PSU) 185W 661-7111 for iMac Retina 4K 21.5-inch 2019
Rear Housing
923-01615

Rear Housing 923-01615 for iMac Retina 4K 21.5-inch 2019
Stand / Leg
923-0266

Stand / Leg 923-0266 for iMac Retina 4K 21.5-inch 2019
Display / LCD Temperature Sensor Cable 923-0280 for iMac Retina 4K 21.5-inch 2019
Display / LCD Temperature Sensor Cable
923-0280

Camera 923-01618 for iMac Retina 4K 21.5-inch 2019
Camera
923-01618

Bluetooth / Wireless Antenna, Upper 923-00567 for iMac Retina 4K 21.5-inch 2019
Bluetooth / Wireless Antenna, Upper
923-00567

Wifi / Wireless Antenna, Middle 923-00569 for iMac Retina 4K 21.5-inch 2019
Wifi / Wireless Antenna, Middle
923-00569

Wifi / Wireless Antenna, Lower 923-00570 for iMac Retina 4K 21.5-inch 2019
Wifi / Wireless Antenna, Lower
923-00570

Hard Drive Lid / Bracket, Left 923-0365 for iMac Retina 4K 21.5-inch 2019
Hard Drive Lid / Bracket, Left
923-0365

Hard Drive Lid / Bracket, Right 923-0364 for iMac Retina 4K 21.5-inch 2019
Hard Drive Lid / Bracket, Right
923-0364

Hard Drive Cradle 923-0326 for iMac Retina 4K 21.5-inch 2019
Hard Drive Cradle
923-0326

Hard Drive Data / Power Cable 923-0461 for iMac Retina 4K 21.5-inch 2019
Hard Drive Data / Power Cable
923-0461

Hard Drive Rubber Bumpers 076-1448 for iMac Retina 4K 21.5-inch 2019
Hard Drive Rubber Bumpers
076-1448

Solid State Drive SSD SSPOLARIS PCIe 661-07309, 661-07312, 661-07313, 661-07320, 661-07588, 661-07589 for iMac Retina 4K 21.5-inch 2019
Solid State Drive SSD SSPOLARIS PCIe
661-07309, 661-07312, 661-07313, 661-07320, 661-07588, 661-07589

Clutch Hinge Mechanism 923-00046 for iMac Retina 4K 21.5-inch 2019
Clutch Hinge Mechanism
923-00046
